longitudinaltension ©n the shell, is illustrated in Fig. 10, and it is easily seen that this deforma-tion is of such a nature that every cross-section of the ring experiences a rotationin its own plane, about some point whose position we have yet to determine.(It will be observed that we are… … » -* < < o <— Fig. 26. — Illustrating theCircumferential Tensions. Fig. 25. Illustrating the Rotation ofthe Cross-section. steel rings which are light in construction, and which are unprovided withbrackets between the leaf and the hub of the ring. It is doubtless very nearlytrue, however,…Locomotives · Steam-boiler explosions
