Figs. 76 and 77. Locomotive for the Austrian State Railways. LOfG. 100 LOCOMOTIVE CATECHISM. exhaust being chilled and thus losing its power of entrainingair with it. Q. Of what is the smoke-box front usually made? A. Cast iron, having in its center a large outward-openingdoor which permits… … Fig. 78. Smoke-box and Fittings (Lengthwise View). I. Exhaust-nozzle. 2. Netting. 3. Deflecting-plate Slide. 4. Deflecting-plateSlide. 5. Spark-ejector. 6. Cleaning-hole and Cap. 7. ^haust-thimbles. Q. How are engines with short front ends prevented fromthrowing too many cinders? A. By diamond…
