Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 369
n the lower end of a vertical lever L, pivoted at P to anoffset piece E attached to the upper guide G and to the steamchest cover H. The upper end of this lever drives a hori-zontal rod R that passes through bearings 6 S 6 carried bythe frame E. From this rod R runs a cord C to the indi-cator drum… … Pre-admissiottv k glm* - Period of Full Steam , ^ Exhaust-*! Fig. 240. Valve Diagram. (Fig. 240) represents the piston stroke on one scale, the valvetravel on another; drawing parallel to this diameter a lineDE, the distance of which from the latter represents the linealvalve lead; parallel to this…
Locomotives
