Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 550
h this arrange-ment? A. To have a safety valve on the receiver, to prevent theback pressure on the high-pressure piston being increased,.which would lessen the power of the high-pressure cylinder RICHMOND COMPOUND. 535 111 the same proportion as that in the low-pressure was in-creased. THE RICHMOND… … Fig. 344. Richmond Two-cylinder Compound,cylinders and then to the exhaust, is shown by arrows; fromthe dry pipe, down the main steam pipe at the right of thefigure to the H. P. chest and cylinder; thence to the horse-shoe-shaped receiver pipe in front of the main steam pipe tothe intercepting…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
