Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 611
ns, on five axles,viz., a four-wheeled bogie in front, two coupled axles, and atrailing carrying axle situated in a Bissell truck. Besides thatit is fitted with an auxiliary driving axle, between the twobogie axles, but not forming part of the bogie, having itsbearings guided by horn plates… … Fig. 394A. Clamp for Broken Rod.sized outside cylinders on the main frames in front of theleading wheels. The auxiliary valve gear is a modificationof Joys. The auxiliary engine is used for starting and climbing;when not in use the auxiliary drivers are held off the railsby springs, and are held…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
