Locomotive catechism; an up-to-date, practical and complete work on the locomotive--treating on the design, construction, repair and running of all kinds of locomotives .. (1908)
Grimshaw, Robert, 1850- [from old catalog] · New York, The N. W. Henley publishing company · leaf 62
Figs. 42, 43, 44, 45, 46 and 47.Valves of Korting Smoke Consumer. and covered with fire-brick except at the air-inlets L and K. Thewalls run up to the heightof the arch; the front wallbeing back of the fluesheet. Steam is admittedat A, oil at B, and air at C.Fig. 41, and also through Land K, Fig.…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
