AIR BRAKES; Westinghouse. 584 Figs. 1445-1447 Fig. 1445 — Engine Truck Brake Cylinder. Names of Parts of Fig. 1445. Follower Stud and Nut Cylinder Gasket Cylinder Body 13 8 2 Push Rod Push Rod Holder Piston and Rod 14 9 3 Push Rod Holder Pin Follower 16 Pressure Head 10 4 Push Rod Pin Packing… … Names of Parts of Fig. 1446. Non-Pressure Head Bolt and Nut Packing Leather 12 7 Cylinder Body 2 Cylinder Gasket Packing Expander 13 8 Piston and Rod 3 Lever Bracket Release Spring 14 9 Non-Pressure Head 4 Lever Bracket Bolt and Nuts Follower Stud and Nut 15 10 Pressure Head 5 Pressure Head Bolt…
