Locomotive engine running and management .. (1899)
Sinclair, Angus, 1841-1919 · New York, J. Wiley & sons; [etc., etc.] · leaf 48
ts for springs and equal-izers that embrace nearly all requirements. The following parts are shown: 1. Forward driving-spring. 2. Second driving-spring. 3. Third driving-spring. 4. Fourth driving-spring. 5. Fifth driving-spring. 6. Forward-truck equalizer. 7. 8, 9, 10. Different kinds of… … XXXVI IN TR OB UC TION. four-wheel engine-truck and of a two-wheel pony-truck.The principal parts are : 1. Center-pin. 2. Swing-bolster. 3. Swing-bolster cross-tie. 4. Swing-bolster hanger. 5. Truck-frame. 6. Truck-pedestal. 7. Truck binder-brace. 8. Equalizer. 9. Spring-hanger. 10. Axle. 11.…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
