Hill, John A. (John Alexander), 1858-1916, Sinclair, Angus, 1841-1919 · New York : American Machinist Pub. Co · leaf 284
ed out, theframes beside the flre-bos were stiffened by puttingan I piece in the center between the frames, andrunning a brace in the shape of an arch-bar fromthe lower rail of the frame and the pedestals overthis I piecLp with both ends titled against the jaws,and secured by fit and taper bolts,… … y. Snaxn- -Sn^ of their own pattern; this filling fits the sides oftlie flange and head of rail, and the bolt holes arecast into it large enough, so that the boHs do nottouch the filling piece, hence do not shear or wear off. All injectors have overflow pipes screwed intothem solid ; there is no…
Railroads · Locomotives
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
