hen the reservoir is being filled, the oil rises until it 122 LOCOMOTIVE LUBRICATORS. reaches the bottom of the pocket, and the air which is en-trapped in the pocket prevents the oil from occupyingthat space when the reservoir is filled, which allows forthe expansion of the oil after it becomes… … TO ALR BRAKE .FIG. 4—PLATE.31. Oil tube 22 is open at the top and is in communicationwith reservoir 12. The lower end of oil tube 22 is con-nected with the oil passages which lead to the under sidesof each of the regulating valves 18. The oil tube andpassages are filled with oil as long as there is…
