Fig. 31. 6. Design a diamond riveted joint such as shown in Fig. 31 for a steelplate f in. thick. Outer cover plate is f in. and inner cover plate is ^^ in.thick; the pitch of outer rows of rivets to be twice that of inner rows.Determine efficiency of joints. 7. The single lap joint with cover… … Fig. 32. 41. Riveted Joints for Narrow Plates.—The joints which havebeen so far described are continuous and but one strip of a widthequal to the pitch or the least common multiple of severalpitches, has been investigated. When narrow plates such as are used in structural work areto be joined by…
