Fig. 38. … 98 MACHINE DESIGN. for the main journal of an engine is shown in Fig.39. In this bearing there is one horizontal adjust-ment, instead of two as in Fig. 38. The main bearing of thespindle in a lathe, as shown inFig. 40, offers a good exampleof symmetrical adjustment.The headstock A has a conicalhole…
