Benjamin, Charles H[enry], 1856- [from old catalog] · New York, H. Holt and company · leaf 159
this coupling should be trued up in alathe after being keyed to the shaft. Jones and Laughlins in their shafting catalogue givethe following proportions for flange couplings. Diam. of Shaft. Diam. of Hub. Length of Hub. Diam. ofCoupling. 2 ^ 3i 8 n 5f 4| 10 3 6f 5i 12 H 8 H 14 4 9 7 16 5 Hi 8| 20… … of this type. It consists of the sleeve S bored withtwo tapers and two threaded ends as shown. The twoconical, split bushings B B are prevented from turningby the feather key K and are forced into the conicalrecesses by the two threaded collars C C and thereby CLUTCHES. 135 clamped firmly to the…
Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
