Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 176
e a two view drawing,one view in half section. Com-pletely dimension. PROB. 78, Fig. 86, Chap.III.—Make a two view drawing,both views in full for the VER-TICAL GUIDE. There are 8holes equally spaced in theflange. Completely dimension. PROB. 79, Fig. 86, Chap.III.—Make a two view draw-ing, one view…
Machinery
