Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 184
Fig. 2S9. Prob. 98. Shaft Drawing. JIGS AND FIXTURES 199. The following problems emphasize points to be considered in shop drafting. … PROB. 102, Fig. 291.—Make a working drawing forthe MAIN CASTING of ajig for the LINK of Fig. 290.The letters A, B, C, etc., arefor reference when making anassembly. Dimensions notgiven are to be worked out bythestudent. Refer to Fig. 292. PROB. 103, Fig. 292.—Draw the JIG DETAILS.Refer to Figs.…
Machinery
