Mechanical drawing for secondary schools (1916)

Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 184

An illustration from Mechanical drawing for secondary schools, 1916, leaf 184
the drawing, following the steps outlined underOrder of Inking the Drawing, page 172. 3. Trim the sheet and press the clotli back into the tack holes. TRACING AND BLUEPRINTINGDATA FOR LETTERING PLATE 21 Given: Plate 21 to reduced size. Fig. 187.Required: To make the plate to an enlarged scale. 179… … Fig. 188. Type Problem. EesertOir Cap. Given Views PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 22 Before starting to draw this plate the student should reviewthe method of drawing tangent lines as described on page 147.
