Machine drawing; a text and problem book for technical students and draftsmen (1921)
Svensen, Carl L. (Carl Lars), 1884- · New York, D. Van Nostrand company · leaf 20
ition—Left Side View. Fig. 18.Second Position—Left Side View. ELEMENTARY PRINCIPLES 9 used when a piece is rather flat and wide. It allows the use of a largerscale. Sometimes it is the only way in which the views can be containedon a given size of drawing paper. The ^rs^ position of the left side…
Machinery
