STEAM TURBINE BEARING 204. The steam turbine bearing shown in Figs. 326, 327, and 328 is for a Type 6,B. F. Sturtevant Steam Turbine. The bearings are split to permit easy adjustment.The two halves are held together with cap screws. The spherical seating makes thebearing self-aligning. The rapidly… … An idea of the assembly may be had by reference to Fig. 73. The adjusting screw(Part No. 2, Fig. 326) is used to screw through the bearing casing cover, causing thespherical seat (Part No. 4, Fig. 326) to grip the Unings (Part No. 7, Fig. 328). Thelock nut (Part No. 3, Fig. 326) is used to hold the…
