conventional representations may be full views or sectional views,either partial or complete. A view of an object is not a picture and isnot to be regarded as such, still we should be careful not to convey a falseimpression of an object or its construction. It is to avoid the possibilityof such… … FiG. 82. Section without Dotted Lines. MACHINE DRAWING 47 mon parts of machinery have been devised to save time. The true pro-jection of a screw thread would involve drawing a helix and when thefrequency with which screw threads occur is considered, the necessityfor using idioms or engineering…
