Sliding End 7 D Fast End 7 Fig. 49.Fig. 53. … Fig. 52. Fig. 51. CORLISS CYLINDERS. PArrEKN MAKING. 31 inner box is first made, the length, width, and depth of/g h in Figs. 49 and 50, and doweled together with irondowel plates like sketch. Build out each side of this in-ner box for about two-fifths of its length to width G, inFig. 46, then…
