g a mortise at R. At S, you see the rebatesin which the panel tongues T are spliced, the panels beingreinforced at a certain distance by these tongues as you seeat V, so that their thickness shall be 0.022 m. You willobserve that the chamfers of the posts X stop below the JOINERY. 239 junctions to… … F10. 57. This gives you the key to the whole joining of the ordinaryand well-made door. The rule is simple ; never weaken thewood on the right of the junctions, always make these in square,and do not exceed the dimensions given by the cut wood. Our single-leafed doors shall be established after…
