A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 345
Bj equal to the radius of the rollers, the curve a l?a^ b^,and form the eccentric to this curve. The degree of expansion can also be very easily changed,if the eccentric is formed of two plates, such as shown inI. and II., Fig. 750, one being turned through a certainangle with respect to the other,… … § 467-] THE STEAM ENGINE. 33: off at about one third of the stroke. If, howev^er, we turnI. through a certain angle before laying it on II., the cen-
