A manual of the mechanics of engineering and of the construction of machines. Designed as a text-book for technical schools and colleges, and for the use of engineers, architects, etc. (1878)
Weisbach, Julius Ludwig, 1806-1871, Du Bois, A. Jay (Augustus Jay), 1849-1915, Buel, Richard H. (Richard Hooker), b. 1842 · New York. J. Wiley & Sons, 1878- · leaf 351
n in itscentral position, while the pistonhas arrived at the other end ofits stroke. The same succession!g now takes place in the returnstroke. Very similar to the above isthe slide valve of Farcot, repre-sented in Fig. 758. Here theback of the slide AAA has sixrectangular orifices for the pas-sage… … ran^-ement is as above. § 470.] THE STEAM ENGINE. 339 slide, so that all may move together. This common mo-tion is, however, limited in either direction by the checkse and <?, and / and /,, the former striking against E and E^and the latter against the ends of the steam chamber.In the position…
Mechanics, Applied · Mechanical engineering
