Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)

Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 127

An illustration from Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines, 1910, leaf 127 — No. -A Stak Eng. Steam 150 1st Rec. 20 2d Rec. -5 Vac. 21 Rev. 128I. H. P., H. P. 457.6 I. H. P., I. P. 317.0 I H P F L. P. 113.5 I. H. P., A. L. P. 123.9 Total, 1,012.0 122 V* MARINE INDICATING Series 6 … I.J-C.F>=*JZ£..3

Indicators for steam-engines · Marine engines

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
