Marine engine indicating; a complete treatise on the indicator and indicator diagrams as applied to marine engines (1910)
Linch, Charles Sutterley, b. 1869 · Boston, American Steam Gauge and Valve Mfg. Co. · leaf 55
nd convert same into pounds, per square inch. Thus, if theordinate is l| long and the scale used was, say, 80 pounds, the pressurewould be 1.75X80 = 140 pounds per square inch. In using 20 ordinates the work is more tedious, but the result amplyrepays for any extra work, as the enlarged diagram is… … J3ot:tom.
Indicators for steam-engines · Marine engines
