Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 241

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 241
The order of teeth, as marked on the diagram, beginning with the fixedgear A, which has 303 teeth; B, on the cross-arm shaft, 40 teeth; D, atthe other end of the cross-arm shaft, ss teeth; E, also fixed to the cross-arm shaft, 40 teeth; F, on the high-speed shaft, 12 teeth; C, on theslowest wheel… … 620. TRANSMISSION GEAR for automobiles. The three inter-mediate gears are pinioned to aseparate plate from the outsidegear, and controlled by a brakestrap. There being two compart-ments and two sets of gear, thebrake strap on each compart-ment controls the speed and thereverse motion. 621. Left…

Mechanical movements
