Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 80

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 80
in supplementary exhaust ports. The piston valves are connected toand operated by the following piston. The exhaust is discharged into STEAM POWER APPLIANCES. 79 the main trunk of the engine through the hollow spool valves andfrom the ports opened by the trunk pistons into the jacketed… … ENGINE. Kipp type. In Kipps re-volving engines the exterior cylin-der, to which a belt may be directlyapplied, it being surrounded by alagging for that purpose, is causedto rotate by the reciprocation oftwo pistons with duplicate heads incylinders whose axes are at rightangles to each other. The…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
