Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 93

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 93
^^ position S for reversing;a^^-^ a R, valve rod connected to the eccentric arm at a. Theelliptic line, /, shows therange of the valve motionand swings to the verticalwith the link and moves the valve within the range of its lap. 197. Valve just opening, forward. 198. Valve just closing, reverse.… … 199. FLE3CIBLE CRANK for marine shafting. The crank pin isfixed in one side and swiveled in theother side of a double crank, asshown, giving flexibiHty to a Hne ofshafting in marine engines.

Mechanical movements
