Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 120

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 120
.--4.G: BALANCED ENGINE. Explosive motor. Secortype. Theis fired in the chamber X between the two pistons H H, whose motion is transmitted to the cranksG G, having equal throw and set at180° apart on the crank shaft. The pistons are connected by theshort connecting rods H H to thevertical levers D… … 273. GASOLINE ATOMIZER AND VAPORIZER The exhaust

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
