Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 216

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 216
ROAD AND VEHICLE DEVICES, ETC. 213 … 542. AUTOMOBILE STEERINGGEAR. A curved and eccentricallymounted cam plate on the handle shaftrevolves against roller arms of the hollowshaft K, moving it forward or back-ward in the socket and sheath D, E.The socket-head spindle, F, accommo-dates difference in length by sliding inthe sheath K. 543.…
