Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 293

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 293
MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 291 758. CENTERING DEVICE FOR A DRILL PRESS. Thedevice consists of a drill shank, A,made to fit the drill spindle; a centering vise with three jaws^ two of which areindicated by C, and a chuck to holdthe combined drill and reamer D.The centering jaws are…
