Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 33

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 33
30 TRANSMISSION OF POWER. … 29. POSITIVE COMBINATIONCLUTCH. The first motion of theclutch handle brings the friction conesinto contact; a further push of thehandle moves the teeth of the clutch intocontact and prevents slipping of the fric-tion cones. The bell-crank arm on thehandle holds the clutch fast in its…
