Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 90

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 90
MOVING BLADES STATIONARYBLADES MOVING BLADES STATIONARY RLAOES MOVING BLADES. III! I I 182. STEAM TURBINE. De Laval type. Vertical sectionshowing form of buckets and nozzles. Steam impinges against theouter edge of the buckets and exhausts at the sides.

Mechanical movements
