Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 100

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 100
al governorof the shaft type mounted in the belt wheel of the main governor.The weight w of this auxiliary governor is provided with a lip, which,in the event of abnormal speed, will be thrown outward so as to en-gage with a small lip, O, on the end of the rocker arm shown. Theother end of this… … g6 STEAM POWER APPLIANCES. 212. SHIFTING ECCENTRIC

Mechanical movements
