Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 313
■Wet-Vacuum Pump Steam-Power Cylinder- Circulating Pump-- Fig. 293.—Typical Surface Condenser With Combined Circulating And Wet-VacuuiPumps Of Reciprocating Type. 292 STEAM POWER PLANT AUXILIARIES [Div. 9 Note.—Water-cooling is used almost exclusively in the operation ofsteam condensers. All… … Drain-- HotWell- Overflow Fig. 294.—Diagrammatic Sectional View Of Buckley Siphon Condenser AndConnections. 335A. The Circulation Of The Water In Surface Condensers may be: (1) A single flow, as where the water passes (Fig. 297)only once through the tubing. That is, the water flows intothe…
Steam power plants · Pumping machinery
