Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 231

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 231
587. RAILWAY TRACK BRAKE. By the double toggle jointsand lever connection, the whole weight of the truck and end of car is brought to bearon the brakeslippers, thelever fulcrumbeing fixed tothe truck frame. … RAILWAY DEVICES AND APPLIANCES, ETC. 227
