Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 242

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 242
at a constant rate of speed drives directly and at different rates of speed a seriesof pinions mounted in a sur-rounding revoluble case orshell, so that by turning theshell one or another of thesecondary pinions may bebrought into operative relationto the parts to be driven there-from. C, a stop… … 238 GEARING AND GEAR MOTION. ETC. 619. EPICYCLIC TRAIN. In which 262,500 revolutions of theleft side shaft must be made to produce one revolution in the right sideshaft.

Mechanical movements
