The order of teeth, as marked on the diagram, beginning with the fixedgear A, which has 303 teeth; B, on the cross-arm shaft, 40 teeth; D, atthe other end of the cross-arm shaft, 33 teeth; E, also fixed to the cross-arm shaft, 40 teeth; F, on the high-speed shaft, 12 teeth; C, on theslowest wheel… … 620. TRANSMISSION GEARfor automobiles. The three inter-mediate gears are pinioned to aseparate plate from the outsidegear, and controlled by a brakestrap. There being two compart-ments and two sets of gear, thebrake strap on each compart-ment controls the speed and thereverse motion. 621. Left hand…
