Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 252

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 252
641. SHORT-RANGE WALKING BEAM. By the interlocking linkage the cylinder andcrank can be brought close together. None of the motions in this linkasre areparallel. The piston rod is the guide to thelast link. … 642. TURNING A SQUARE BYCIRCULAR MOTION. A device onehundred and fifty years old. Not an eco-nomical device for square work, but ap-plicable for irregular and fluted work. Pos-sibly the original idea of the rose lathe. 643. DOUBLE-LINK UNIVERSAL JOINT. This arrangement allows of a large deviating…

Mechanical movements
