Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 67

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 67
107. FUEL OIL BURNER. Plan and sections of the crudeoil burners used on the locomotives of the Southern Pacific Railroad. … jr~r,-,-;:;-- ■■ ~ , ,■;■;,■-, ;^, END VIEV/ The steam, oil, and air chambers are very wide and spread a broadflame. Nos. 108, 109, no, in, show the burner in detail. GENERATION OF POWER, STEAM. 63 112. LIQUID FUEL BURNER. Urquhart Locomotive type. The air nozzles are fixed, steamnozzle is movable…
