STEAM POWER APPLIANCES. 75 … 147. HIGH SPEED VERTICAL EN-GINE. Rhodes type. Valve of the gridironbalanced type, with valve gear of a novel de-sign giving a quick and full movement of thevalve through a rawhide disk, H, rolling on anirregular cam on the shaft and made adjustablefor time of cut off between the limit of 3/8…
