The practical draughtsman's book of industrial design and machinist's and engineer's drawing companion : forming a complete course of mechanical, engineering, and architectural drawing (1863)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Johnson, William, 1823-1864 · Philadelphia : H.C. Baird · leaf 185
f gear by means of an eccentric, whilst i and h are connectedby change-wheels. In the same way, face-cams and other formsmay be shaped by varying the connections. Angular and diagonal work in any position may also be workedin this lathe without tilting the tool, by means of the same set…
Mechanical drawing
