LEI^ 21 To draw an arc of a givenradius tangent to two con-verging lines—Let A B andC D be the converging linesand E F the given radius.At any points, I and J, drawperpendiculars to A Band C D. (Problem 4.)Make I G and J H equal toE F. Draw H K and G L GEOMETRICAL PROBLEMS 191 parallel to the lines… … To draw an arc of a givenradius tangent to two circlesof fixed diameters—Let CD be the given radius.From A and B, the centersof the given circles, drawany indefinite lines A Kand B L. Make G K andH L equal to C D. WithB as a center and radiusB L, draw arc 1. WithA as a center and radiusA K, draw…
