Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 149
Fig. 148. Vise Anvil DATA FOR DRAWING PLATE U Given: Perspective sketches, Figs. 148, 149, 150, and 151.Required: To draw an orthographic sketch of the object … Fig. 149, Towel Hanger
Mechanical drawing
