Crawshaw, Fred D. (Fred Duane), b. 1874, Phillips, J. D. (James David), 1869- joint author · Chicago, New York, Scott, Foresman and company · leaf 49
0, 6, 9 DATA FOR LETTERING PLATE 3 Given: Plate 3 to reduced size. Fig. 85.Required: To make the plate to an enlarged scale. 44 MECHANICAL DRAWING DATA FOR EXTRA DRAWING PLATE Given: The dimensioned sketch of a wall bracket, Fig. 36,with the upper surface of the enclosing solid 3^ below the levelof… … Fig. 36. Wall Bracket Cylindrical Objects PREPARATORY INSTRUCTIONS FOR DRAWING PLATE 4 The Veriical Measure Cylinder. As stated before, the cubeis the basic form for the perspective sketching in this course. Tosecure a measure unit for cylindrical objects a cylinder is in-scribed in a measure cube…
Mechanical drawing
