=T-« TT^ … 166 MECHANICAL DRAWING. PLATE XXIV. Fig. 124. Top and side views^ and a frofit view^ ojte half of whichshows a section^ of a bearing for the end of a shaft which moves back andforth in a plane^ and so requires a beaiHng that rotates. The shaft restsupon a box of co7nposition B, which is replaced…
