Mechanical drawing. Elementary and advanced (1910)

Reid, John S. (John Simpson), 1856- · New York, J. Wiley & sons; [etc, etc.] · leaf 232

An illustration from Mechanical drawing. Elementary and advanced, 1910, leaf 232 — cal drawing of the finished piece andFig. 280 the orthographic views. Figs. 281 and 282 show thedeveloped patterns with a TV allowance on the edges for seams.See model in the drafting room. Prob. 3 requires the drawing of a pattern for a flat-sidedtapering box shown in isometric at Fig. 283. Figs.…

Mechanical drawing · Drawing instruments · Lettering

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
