Mechanical drawing. Elementary and advanced (1910)
Reid, John S. (John Simpson), 1856- · New York, J. Wiley & sons; [etc, etc.] · leaf 59
Fi^ 75. To Describe a Spiral of any Number ofREVOLUTIONS, E.G., 2.—Divide the circle into any num-ber of equal parts as A, B, C, etc., and draw radii. Dividethe radius A12 into a number of equal parts correspondingwith the required number of revolutions and divide theseinto the same number of equal…
