. 105, we be-lieve that our readers will agree with usthat excepting under favorable conditions that such a view as Fig. 105 is prefer-able for some reason or other to separateelevations, so we must take the matterinto consideration in connection with thiswork. We do not think it would be… … ~R_oo Fig. 108. the work of such a system as the oneshown in our illustration is shown moreclearly and to better advantage by mak-ing separate elevations of different partsof the work, viewing the several partsfrom the most advantageous position,rather than to show it all in one eleva-tion.…
