Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 210
considering it in advance of other forms. 80. Three-way and Four-way Valves.—It will be appar-ent when one end of a cylinder is to be put into alternatecommunication with boiler and exhaust-pipe that the ordinarythree-way valve can be made to fill these requirements bycausing it to vibrate through… … FROM CYLINDER Fig. 121. Fig. 121 shows the position 900 distant when the cylinder hasbeen connected to the exhaust-pipe. It will be seen that the FROM BOILER FROM BOILER
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
